Modbus/PROFIBUS DP Gateway PM-127
Modbus / PROFIBUS
price click click shipping
Product Name: Modbus/PROFIBUS DP Gateway
Order Code: PM-127
Description:

The gateway PM-127 establishes communication between serials and PROFIBUS DP, and can connect multiple devices with Modbus RTU/ASCII (RS485) interface to PROFIBUS DP.

Technical Specification:
  1. Acts as a PROFIBUS DP slave on PROFIBUS DP, while Modbus master, Modbus slave can be selected
  2. Complete PROFIBUS DP V0 slave functionality according to EN50170 (IEC61158)
  3. Automatic baud rate detection on PROFIBUS DP(9600 bit/s ~ 12 Mbit/s)
  4. Max Input: 244 bytes
    Max Output: 244 bytes
    Max Input+Output: 488 bytes
  5. Power Supply: 11V-30VDC, Maximum Power Dissipation: 2W
  6. Operating Temp.: -40°F to 158°F (-40 oC to 70 oC), Rel. Humidity: 5%-95% RH non-condensing
  7. Dimension(W*H*D):100mm* 70mm * 25mm(3.95in*2.75in*1.00in)
  8. Mounting: DIN Rail Mounting(35mm)
  9. Protection Level: IP20
